Owners manual MELEX 4XX MELEX 2021/01
32
5.5. Fuses Exchange
5.5.1.Vehicle main fuse 200A (250A)
Fuse is located in the batteries compartment: on the
mudguard.
Fuse 250A goes only with models with 5/8 kW AC motor.
In the case of a blown fuse, locate and remove the cause of the fuse
blown and then replace it with a new one.
In order to change the fuse (2) disconnect batteries, take off the
rubber cap (1), loose the nuts (4). Remove the blown fuse (2),
insert new one and screw nuts (4).
Drawing 5–5–1-1
5.5.2. Fuse-and-relay box location
Drawing 5-5-2-1
The fuse box is located behind the dashboard. To get into the box, unscrew the screws and
remove the control panel board.
