Owners manual MELEX 4XX MELEX 2021/01
52
9. ON - BOARD CHARGER
On-board charger ABC 1600W with DEFA socket
Charger is adapted to 48V batteries set
Drawing 9-1
1. Charging signal lamp
2. Socket 230Vac of on-board charger (DEFA)
3. Power supply cable from DEFA kit
On-board charger TCE 48V/25 AMPER with DEFA socket in vehicles 4xx excluding 427,
447
Charger is adapted for charging of 48V batteries set (8x6V)
Drawing 9-2
1. Charging signal lamp (also on charger) 4. „eco” sticker
2. Socket 230Vac of on-board charger (DEFA) 5. Warning sticker
3. Power supply cable from DEFA kit
