Adapter Card Interfaces
Rev 1.6
Mellanox Technologies
20
The PCI VPD (Vital Product Data) layout, for each of the adapter cards complies with the format
defined in the PCI 2.3 Specification, Appendix I.
Table 10 - MHQH[12]9B-XTR
Offset
(Decimal)
Item Value Format Description
0 Large Resource Type ID String Tag
(0
x02)
0x82
1 Length [7:0] LSB 0xA
2 Length [15:8] MSB 0x0
3 Data FALCON QDR STR
13 Large Resource Type VPD-R Tag
(0
x10)
0x90
14 Length [7:0] LSB 0x4F
15 Length [15:8] MSB 0x00
16 VPD Keyword PN STR Add in Card Part Number
18 Length 0x15
19 PN PN %STR_SPC
40 VPD Keyword EC STR Engineering Change Level of the card
(rev
)
42 Length 0x2
43 Revision RV %STR PCB revision
45 VPD Keyword SN STR Serial Number
47 Length 0x18
48 SerialNumber %STR_SPC “00..00XXXX..XX”
72 VPD Keyword V0 STR Misc Information
74 Length 0x10
75 Data PCIe Gen2 x8 STR_SPC
91 VPD Keyword RV STR
93 Length 0x1
94 Data 0,93 %CS0
95 Large Resource Type VPD-W Tag
(
0x11)
0x91
96 Length [7:0] LSB 0x9D
97 Length [15:8] MSB 0x00
98 VPD Keyword V1 STR EFI Driver version
100 Length 0x6
101 Data N/A STR_SPC
107 VPD Keyword YA STR Asset Tag
109 Length 0x20
110 Data N/A STR_SPC “N/A”
142 VPD Keyword RW STR Remaining read/write area
144 Length 0x6E
145 Data STR_ZERO Reserved (0x00)
255 Small Resource Type END Tag
(
0x11)
0x78
