Table 12 - MH[QR]H19C-X[STN]R VPD
Offset
(Decimal)
Item Value Format Description
0 Large Resource Type ID String Tag
(0
x02)
0x82
1 Length [7:0] LSB 0xF
2 Length [15:8] MSB 0x0
3 Data ConnectX-2 QSFP STR
18 Large Resource Type VPD-R Tag
(0
x10)
0x90
19 Length [7:0] LSB 0x4F
20 Length [15:8] MSB 0x00
21 VPD Keyword PN STR Add in Card Part Number
23 Length 0x15
24 PN PN %STR_SPC
45 VPD Keyword EC STR Engineering Change Level of the card
(rev
)
47 Length 0x2
48 Revision RV %STR PCB revision
50 VPD Keyword SN STR Serial Number
52 Length 0x18
53 SerialNumber %STR_SPC “00..00XXXX..XX”
77 VPD Keyword V0 STR Misc Information
79 Length 0x10
80 Data PCIe Gen2 x8 STR_SPC
96 VPD Keyword RV STR
98 Length 0x1
99 Data 0,98 %CS0
100 Large Resource Type VPD-W Tag
(
0x11)
0x91
101 Length [7:0] LSB 0x98
102 Length [15:8] MSB 0x00
103 VPD Keyword V1 STR EFI Driver version
105 Length 0x6
106 Data N/A STR_SPC
112 VPD Keyword YA STR Asset Tag
114 Length 0x20
115 Data N/A STR_SPC “N/A”
147 VPD Keyword RW STR Remaining read/write area
149 Length 0x69
150 Data STR_ZERO Reserved (0x00)
255 Small Resource Type END Tag
(
0x11)
0x78
