3. If the old gasket is still on the card, remove it before installing the new bracket. Make sure
that only one gasket per port is used.
Figure 18: Gasket Installation
4. Place the bracket onto the card until the screw holes line up.
Do not force the bracket onto the card. You may have to gently push the LEDs using a
small screwdriver to align the LEDs with the holes in the bracket.
5. Screw on the bracket using the screws and washers saved from the procedure above.
