Table 11 - MHRH[12]9B-XT[CR]
Offset
(Decimal)
Item Value Format Description
0 Large Resource Type ID String Tag
(0
x02)
0x82
1 Length [7:0] LSB 0xA
2 Length [15:8] MSB 0x0
3 Data FALCON DDR STR
13 Large Resource Type VPD-R Tag
(0
x10)
0x90
14 Length [7:0] LSB 0x4F
15 Length [15:8] MSB 0x00
16 VPD Keyword PN STR Add in Card Part Number
18 Length 0x15
19 PN PN %STR_SPC
40 VPD Keyword EC STR Engineering Change Level of the card
(rev
)
42 Length 0x2
43 Revision RV %STR PCB revision
45 VPD Keyword SN STR Serial Number
47 Length 0x18
48 SerialNumber %STR_SPC “00..00XXXX..XX”
72 VPD Keyword V0 STR Misc Information
74 Length 0x10
75 Data PCIe Gen2 x8 STR_SPC
91 VPD Keyword RV STR
93 Length 0x1
94 Data 0,93 %CS0
95 Large Resource Type VPD-W Tag
(
0x11)
0x91
96 Length [7:0] LSB 0x9D
97 Length [15:8] MSB 0x00
98 VPD Keyword V1 STR EFI Driver version
100 Length 0x6
101 Data N/A STR_SPC
107 VPD Keyword YA STR Asset Tag
109 Length 0x20
110 Data N/A STR_SPC “N/A”
142 VPD Keyword RW STR Remaining read/write area
144 Length 0x6E
145 Data STR_ZERO Reserved (0x00)
255 Small Resource Type END Tag
(
0x11)
0x78
ConnectX®-2 VPI Single and Dual Port QSFP InfiniBand and Ethernet Adapter Card User Manual Rev 1.6
