Table 13 - MHRH19B-X[ST]R
Offset
(Decimal)
Item Value Format Description
0 Large Resource Type ID String Tag
(
0x02)
0x82
1 Length [7:0] LSB 0xB
2 Length [15:8] MSB 0x0
3 Data KESTREL DDR STR
14 Large Resource Type VPD-R Tag
(
0x10)
0x90
15 Length [7:0] LSB 0x4F
16 Length [15:8] MSB 0x00
17 VPD Keyword PN STR Add in Card Part Number
19 Length 0x15
20 PN PN %STR_SPC
41 VPD Keyword EC STR Engineering Change Level of the card
(r
ev)
43 Length 0x2
44 Revision RV %STR PCB revision
46 VPD Keyword SN STR Serial Number
48 Length 0x18
49 SerialNumber %STR_SPC “00..00XXXX..XX”
73 VPD Keyword V0 STR Misc Information
75 Length 0x10
76 Data PCIe Gen2 x8 STR_SPC
92 VPD Keyword RV STR
94 Length 0x1
95 Data 0,94 %CS0
96 Large Resource Type VPD-W Tag
(
0x11)
0x91
97 Length [7:0] LSB 0x9C
98 Length [15:8] MSB 0x00
99 VPD Keyword V1 STR EFI Driver version
101 Length 0x6
102 Data N/A STR_SPC
108 VPD Keyword YA STR Asset Tag
110 Length 0x20
111 Data N/A STR_SPC “N/A”
143 VPD Keyword RW STR Remaining read/write area
145 Length 0x6D
146 Data STR_ZERO Reserved (0x00)
255 Small Resource Type END Tag
(
0x11)
0x78
ConnectX®-2 VPI Single and Dual Port QSFP InfiniBand and Ethernet Adapter Card User Manual Rev 1.6
Mellanox Technologies
23
