Mellanox Technologies MHQH29C-XTR User Manual

ConnectX®-2 VPI Single and Dual Port QSFP InfiniBand and Ethernet Adapter Card User Manual Rev 1.6
Mellanox Technologies
55
16 GND GND
17 RXP_1 Rx1p
18 RXN_1 Rx1n
19 GND GND
20 GND GND
21 RXN_2 Rx2n
22 RXP_2 Rx2p
23 GND GND
24 RXN_4 Rx4n
25 RXP_4 Rx4p
26 GND GND
27 ModPrsl_Port0 Mod PrsL
28 IntL IntL
29 VccTx
30 Vcc1
31 LPMode_Port0 LPMode
32 GND GND
33 TXP_3 Tx3p
34 TXN_3 Tx3n
35 GND GND
36 TXP_1 Tx1p
37 TXN_1 Tx1n
38 GND GND
Table 25 - Connector Pin Name and Number to Signal Name Correspondence
Connector Pin Number Connector Pin Name Port A Signal Name
