Feature Value
Memory: SDRAM: 8GB DDR3L 1600 MT/s SO-DIMM
Storage: 16GB Dual Channel MLC M.2-SATA SSD
Throughput 3.2Tb/s
7.5 SN2010 Series
Feature Value
Mechanical Size: 43.8mm (H) x 200mm (W) x 508mm (D)
1.72" (H) x 7.87" (W) x 20" (D)
Mounting: 19” Rack mount
Weight: 4.500kg
Speed: 10/25/40/50/56/100GbE per port
Connector cage: 18 ports of 10/25GbE and 4 splittable ports of
40/100GbE
Environmental Temperature: Operational: 0° to 40°C
Non-Operational: -40° to 70°C
Humidity: Operational: 10% - 85% non-condensing
Non-Operational: 10% - 90% non-condensing
Altitude: 3050m
Noise level: 73.7 dB(A)
Regulatory Safety/ EMC: CB, cTUVus, CE, CU, S_Mark, CE, FCC, VCCI, ICES,
RCM, BSMI, KCC, CCC
RoHS: RoHS complaint
Power Input Voltage: 100-127VAC 50/60Hz 4.5A; 200-240 50/60Hz 2.9A
Global Power Consumption: Typical power with passive cables (ATIS): 57W
Max power with optical cables (assuming 3.5W per each
QSFP28 port): 250W
Main Devices CPU: Intel x86 2.40GHz Quad Core
PCIe: 4x Gen2.0
