3.11.1.4 SN2410 Splitting Options
The top QSFP28 ports – 49, 51, 53, 55 (green) – are splittable to 4 SFP28 ports each.
All QSFP28 ports can be split into two QSFP28 ports.
The bottom QSFP28 ports – 50, 52, 54, 56 (gray) – are blocked when the upper ports are in split mode.
3.11.1.5 SN2100 Splitting Options
All QSFP28 ports are splittable. Each port can be split into 4xSFP28 (10/25G) or 2xQSFP28 (50G) ports. There are no blocking
requirements.
3.11.1.6 SN2010 Splitting Options
All QSFP28 ports are splittable. Each port can be split into 4xSFP28 (10/25G) or 2xQSFP28 (50G) ports each. There are no blocking
requirements.
