LED Behavior Description Action Required
Flashing Green The system is booting up. Wait up to five minutes for the end of the booting
process.
Solid Red Major error has occurred. For example,
corrupted firmware, system is overheated etc.
If the System Status LED shows red five minutes
after starting the system, unplug the system and
call your Mellanox representative for assistance.
4.8.2 Fan Status LED
Fan Status LED in SN2700 - Front and Rear Sides
Both of these LEDs in the red ovals show the fans’ status.
System Status LEDs - Front Side in SN2740
The LED in the red oval shows the fans’ status.
Fan Status LED in SN2410 - Front and Rear Sides
Both of these LEDs in the red ovals show the fans’ status.
Fan Status LED in SN2100
The SN2100 systems have a front fan LED only.
Fan Status LED in SN2010
