Both of these LEDs in the red ovals show the system’s status.
System Status LEDs - Front and Rear Sides in SN2410
Both of these LEDs in the red ovals show the system’s status.
System Status LED in SN2100
The LED in the read oval is located on the front panel of SN2100. There are no LEDs in the rear
panel of SN2100.
System Status LED in SN2010
The LED in the read oval is located on the front panel of SN2010. There are no LEDs in the rear
panel of SN2010.
System Status LED Assignments
LED Behavior Description Action Required
Solid Green The system is up and running normally. N/A
It may take up to five minutes to turn on the system. If the System Status LED shows red after five minutes, unplug the
system and call your Mellanox representative for assistance.
