Feature Value
Regulatory Safety/ EMC: CB, cTUVus, CE, CU, S_Mark, CE, FCC, VCCI, ICES,
RCM, BSMI, KCC, CCC
RoHS: RoHS complaint
Power Input Voltage: 100-127VAC; 50/60Hz 3.5A; 200-240 50/60Hz 2.9A/
192-288VDC (not certified)
Global Power Consumption: 40GbE Models -
Typical power with passive cables (ATIS): 140.4W
(same as the 100GbE models)
Max power with optical cables (assuming 2W per port):
266W
100GbE Models -
Typical power with passive cables (ATIS): 140.4W
Max power with optical cables (assuming 3.5W per
port): 335W
Main Devices CPU: Intel x86 2.40GHz Quad Core
PCIe: 4x Gen2.0
Switch: Mellanox Spectrum
Memory: 8GB DDR3 RAM, 16G SSD
Throughput 6.4Tb/s
7.3 SN2410 Series
Feature Value
Mechanical Size: 43.9mm (H) x 438mm (W) x 394mm (D)
1.72"(H) x 17.24"(W) x 15.5"(D)
Mounting: 19” Rack mount
Weight: 1 PSU weight 6.726kg (14.8 lb)
2 PSU weight 7.526kg (16.6 lb)
Speed: 10/25GbE per port (ports 1-48), 10/25/40/50/56/100GbE
per port (ports 49-56)
Connector cage: 48xSFP28 and 8xQSFP28
