POWERHEAD
90-883728 JULY 2001 Page 4A-53
5. Lubricate center main crankshaft roller bearings and races with light oil.
51854
a
b
a-Install so larger of the 3 holes is toward bottom end of crankshaft
b-Verify retaining ring bridges the separating lines of the bearing race
6. Place center main crankshaft roller bearings on upper and lower main bearing journals
as shown.
7. Install center main bearing races as shown.
8. Secure center main bearing races together with retaining rings. Make sure retaining ring
bridges the separating lines of the bearing race.
FLYWHEEL END
DRIVE SHAFT END
58614
a
a
a
58617
a-Center Main Bearing Races
