MAINTENANCE
99
Description
N
lb.
New Belt
489
110
Used Belt
400
90
2.
Loosen
the
5
/8 in
.
locking
nut
on
the
adjusting
screw
. Leave
the wrench on the adjustment nut.
3.
Use
a
5/16 in
.
socket
and tighten
the
adjusting
screw
until
the
belt tension conforms to the correct setting on the gauge.
4.
Hold the adjustment stud and tighten the 5/8 in locking nut.
a
c
10287
b
a -
Belt tensioner pulley
b -
Adjustment locking nut
c -
Adjustment screw
5.
Remove the belt tension gauge from the belt.
6.
Run the engine for a few minutes and re‑check the tension.
