SPECIFICATIONS
27
6. NXT¹/SSM - The running rotation is stamped on the back of
the gearcase strut.
Engine Model/Horsepower: ________________________
Engine Serial Number: ________________________
Transom Assembly Serial Number:
________________________
Sterndrive Serial Number & Gear Ratio:
________________________
Propeller Number & Pitch: _________________________
Running Rotation: _________________________
Hull Identification Number: _________________________
Boat Model & Length: _________________________
General Engine Specifications (HP700)
Crankshaft Horsepower
1.
700 HP (522 kW)
Displacement 8.2 L (502 c.i.)
Cylinder arrangement V‑8
Bore 114 mm (4.47 in.)
Stroke 101.6 mm (4.0 in.)
Compression ratio 7.7:1
Supercharger 3.3 L Screw‑type compressor
Altenator 90 amp / 1278 watt
Battery requirements 750 CCA 950 MCA
Ignition type
PCM 03 Distributorless with sequential individual
coils
Engine firing order 1 8 4 3 6 5 7 2
Spark plug type (NGK BPR6ES)
Spark plug gap 0.889 mm (0.035 in.)
Fuel system
Sequential Fuel Injection with mechanical and
electric fuel pumps
1. Kilowatts/horsepower rating is in compliance with the SAE J1228/ISO 3046
Standard. Usable power will be reduced by gear losses.
