a - Transom serial number
b - NXT¹ serial number, drive
overall ratio and rotation
c - NXT¹/SSM drive rotation
d - NXT¹/SSM serial number
and drive overall ratio
SERIAL NUMBERS RECORD
The serial numbers are the manufacturer's keys to numerous
engineering details that apply to your Mercury Marine power
package. When contacting your authorized Mercury Marine dealer
about service, always specify model and serial numbers.
1. The engine serial number is printed on the placard located on
the heat exchanger.
2. The Transom serial number is located on the starboard side
of the outer transom assembly under the plastic transom
cover.
3. NXT¹ - Drive rotation, overall ratio, and serial number are all
located under the cover or tie bar plate on the top of the upper
driveshaft housing.
4. NXT¹/SSM - The serial number is located on the starboard
underside of the upper gear housing.
5. NXT¹/SSM - The gear ratio is stamped on the bolt head
located next to the serial number label.
