MAINTENANCE
62
1. Stop the engine.
2. Allow approximately five minutes for the oil to drain into the oil
pan. The boat must be at rest in the water or at the
approximate angle that it would be if setting in the water.
3. Remove the dipstick, wipe it clean, and re‑install it all the way
into the dipstick tube.
4. Remove the dipstick and check the oil level. The oil level must
be between the "OK RANGE" and the "ADD" marks.
5. If the oil level is at or below the "ADD" mark, remove the oil
filler cap (port or starboard). Add enough oil to bring the level
into the "OK RANGE" on the dipstick. Do not overfill.
IMPORTANT: Do not overfill the crankcase with oil.
a - Oil level dipstick
b - Crankcase oil filler cap
Tube Ref No. Description Where Used Part No.
Kendall GT-1 SAE
20W50
Engine crankcase Obtain Locally
