MAINTENANCE
64
2. Remove the fill cap/dipstick and observe the level. The oil level
must be between the lower and upper marks.
3. Add power steering fluid if required to bring the oil level up to
the full mark on the cap/dipstick.
a - Reservoir cap
b - Add fluid mark
c - Full fluid mark
Tube Ref
No.
Description Where Used Part No.
114
Power Trim and
Steering Fluid
Power steering pump 92-858074K01
4. Install the cap/dipstick.
CHECKING FUEL PUMP SIGHT TUBE
NOTE: The mechanical fuel pump has a clear plastic tube
connected to the back of the fuel pump, which is routed to the
throttle body of the supercharger. If the mechanical fuel pump's
internal diaphragm ruptures, fuel is by‑passed into the plastic
tube. This indicates that the fuel pump needs replacement.
