5. Spray a liberal amount of air filter cleaner onto the entire air filter element, and allow it to soak for ten minutes. Do not use
other detergents or diesel.
Tube Ref No. Description Where Used Part No.
Air Filter Cleaning Kit Air filter element 8M0140465
6. Rinse off the air filter element with low pressure water. Always flush from the clean side to the dirty side. This will remove
the dirt and does not drive it into the filter.
7. After rinsing, shake off any excess water and allow it to air dry naturally, or in the sun. Do not use compressed air.
8. Reoil the air filter element after cleaning. Apply air filter oil (included with Air Filter Cleaning Kit) down each pleat. Wait ten
minutes and reoil any light visible spots.
Tube Ref No. Description Where Used Part No.
Air Filter Cleaning Kit Oil air filter pleats 8M0140465
9. Install the silencer tube into the air filter.
a - Silencer tube
b - Air filter
10. Install the air filter assembly onto the engine.
11. Secure the air filter assembly to the air filter base with the clamp.
a - Air filter assembly
b - Clamp
Section 5 - Maintenance
Page 54 90-8M0117076 eng FEBRUARY 2018
