Antifreeze Specification
ASTM D4985 or ASTM D6210
Tube Ref No. Description Where Used Part No.
Heavy Duty Diesel Engine
Coolant Antifreeze
Cooling system 8M0124421
10. Install the pressure cap at the top of the engine.
11. Verify the engine is supplied with water and start the engine. Run the engine for ten minutes to purge the system of
trapped air.
12. Stop the engine and allow it to cool. Do not remove the pressure cap when the engine is hot. When the engine is cool,
remove the cap and top off the coolant level to the surface that the cap seals against. There should be no air volume below
the cap.
IMPORTANT: Running the engine for a short time, stopping the engine, and then checking the fluid level, may need to be
done several times to ensure the system is completely purged of trapped air. Failure to purge all of the trapped air, may
cause the engine to overheat.
13. Replace the top cover and secure with the ten screws removed in step 2. Tighten the screws to the specified torque.
Description
Nm lb‑in. lb‑ft
Top cover screws (10) 10 ± 1 88.5 ± 8.8 –
14.
Check the coolant level in the coolant recovery reservoir. Refer to Inspect the Coolant Recovery Reservoir Fluid Level.
Air Filter
Clean and replace the air filter at the prescribed intervals, or when specified by the air filter restriction indicator. Refer to
Maintenance Schedules.
1. Release the clamp securing the air filter to the base.
IMPORTANT: Once the clamp is released, the air filter assembly will be loose. Be careful not to drop the air filter
assembly.
a - Air filter assembly
b - Clamp
2. Remove the air filter assembly from the engine. Replace if necessary, or clean as follows.
3. Remove the silencer tube from the inside of the air filter and set aside.
a - Silencer tube
b - Air filter
4. Tap the air filter element to dislodge any large dirt particles. Gently brush the air filter element with a soft bristle brush.
Section 5 - Maintenance
90-8M0117076 eng FEBRUARY 2018 Page 53
