Engine Specifications
Description Specifications
Kilowatt/horsepower 353 kW (480 mHP) 368 kW (500 mHP) 404 kW (550 mHP)
Displacement
6.7 L (409 in.
3
)
Bore 104 mm (4.094 in.)
Stroke 132 mm (5.197 in.)
Full power engine rated speed
(RPM)
3200
Engine cruise rated speed
(RPM)
2900
RPM at idle 600 ± 25
Oil pressure at idle 2.4 ± 0.4 bar (35 ± 6 psi) (engine warm)
Oil pressure at WOT 4.2 ± 0.5 bar (61 ± 7 psi) (engine warm)
Oil temperature 120 °C (248 °F) (maximum)
Thermostat 78 ± 2 °C (172.4 ± 3.6 °F)
Electrical system 12‑volt negative (–) ground, 24‑volt negative (–) ground models available
Alternator rating 1260 W, 14 V, 90 A
Recommended battery 1450 CCA, 1850 MCA, or 230 Ah
Fluid Specifications
IMPORTANT: All capacities are approximate fluid measures.
6.7L Diesel Engine
IMPORTANT: You may need to adjust the engine fluid levels depending on the installation angle and cooling systems (heat
exchanger and fluid lines).
Always use the dipstick to determine the exact quantity of oil or fluid required.
All models Capacity Fluid Type Part Number
Engine oil (with filter) 19 L (20.1 US qt) 15W‑40 4‑cycle Diesel Engine Oil 92‑858042K01
Closed cooling system 24.5 L (25.9 US qt)
Heavy Duty Diesel Engine Coolant Antifreeze
ASTM D4985 or ASTM D6210
8M0124421
Approved Paints
Description
Part Number
Mercury Cold Fusion White 8M0094988
Mercury Light Gray Primer 92‑80287852
Mercury Phantom Black 92‑802878Q1
ZF Marine Transmissions
An identification plate is secured to each ZF marine transmission. The gear ratio, serial number, and model number of the
transmission are printed on the identification plate.
NOTE: The system oil volumes specified are for the complete Mercury Diesel assembly; the transmission, transmission oil
cooler, and transmission oil lines. Always use the dipstick to assure proper oil level when replenishing or filling oil.
Section 4 - Specifications
Page 40 90-8M0117076 eng FEBRUARY 2018
