GETTING STARTED
Page 2-6 90-892133 JULY 2003
Display Screens
Data Display Screens
Glossary
Data
Screen Directory Location
Engine Data Screen(s)
Engine data screen(s) is a group of displays
showing various engine data.
Engine RPM and Speed
Displays engine RPM and boat speed.
Engine RPM Synchronizer
Twin Engines – Displays the difference in en-
gine speed (RPM) between the port and star-
board engines
Peak Speed at RPM
This screen records the top speed the boat
reached and associated engine RPM as mea-
sured since the last reset.
Trim Position
Display indicates the propulsion unit position
achieved by setting trim and trailer position.
Troll Control
Maintain a trolling speed without using the
throttle.
To Next Page
