Display Screens
Data Display Screens
Glossary
Data
Screen Directory Location
Depth Plot Line
Displays a plot line of depth vs. time as re-
corded over the last 16 seconds.
Environment
Displays speed, depth, air temperature, and
sea water temperature.
Estimated Fuel Range
Displays estimated range and fuel remaining,
as well as current total fuel flow.
Navigation Screen 1
Displays a compass and shows direction to a
targeted waypoint.
Navigation Screen 2
Displays navigating data to a waypoint.
Seawater Temperature Plot LIne
Displays a plot line of seawater temperature
vs. time as recorded over the last 80 seconds.
Also displays the current water temperature.
