Mercusys MW300RE User Manual

Connect the Extender to the Internet 6
Using Your Web Browser (PC UI)
1 Power On
Plug the extender into a power outlet near your router, and the Signal LED
turns solid red.
2 Configure
1) Connect your wireless device to the extender’s wireless network
MERCUSYS_RE_XXXX.
The default SSID (network name) can be found on the
product label at the back of the extender.
2) Launch a web browser and type http://mwlogin.net in the address bar.
Create a login password, then click Log in.
3) Click Ne xt to start Quick Setup.

Mercusys MW300RE Specifications

General

Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Certification	CE
Product color	White
LED indicators	Yes
Sustainability certificates	RoHS
Antenna type	External
Antennas quantity	3
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK
Wi-Fi data rate (max)	300 Mbit/s
Power consumption (max)	4.3 W
Power consumption (typical)	3 W
Type	Network repeater
Maximum transfer distance	- m
Package depth	121.5 mm
Package width	150.5 mm
Package weight	250 g
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	74.8 mm
Width	101 mm
Height	75.8 mm
