22
BASIC SETTINGS
PEDESTRIAN COMMAND
25
Within the Basic Setting, navigate through the menu screen until you find “MAIN MENU
PEDESTRIAN".
1. Press the “P” button to enter this setting (figure 1).
2. Press the “+” or “-“ buttons to navigate through the options.
3. You can select the following options:
• OPEN 1.5 METERS
• OPEN 2 METERS
• OPEN 3 METERS
4. To confirm the setting, press the “P” button to save and return to the main menu
screen.
SP
+-
MAIN MENU
PEDESTRIAN
figure 1
DELAY MOTOR 2 IN OPEN DIRECTION
26
Within the Basic Setting, navigate through the menu screen until you find
“MAIN MENU DELAY MOTOR 2 - OPEN".
1. Press the “P” button to enter this setting (figure 1).
2. Press the “+” or “-“ buttons to navigate through the options.
3. You can select the following options:
• No
• Second Delay
• Second Delay
• 3 Second Delay
• 4 Second Delay
4. To confirm the setting, press the “P” button to save and return to the
main menu screen.
SP
+-
MAIN MENU
DELAY MOTOR 2 - OPEN
figure 1
INPUT COMMAND
24
Within the Basic Setting, navigate through the menu screen until you find “MAIN MENU
INPUT 1”.
1. Press the “P” button to enter this setting (figure 1).
2. Press the “+” or “-“ buttons to navigate through the options.
3. You can select the following options:
• OPEN-CLOSE-OPEN
• OPEN-STOP-CLOSE-STOP-OPEN
• OPEN-STOP-CLOSE-OPEN
• PEDESTRIAN OPENING
• STOP
• OPEN ONLY
• CLOSE ONLY
• OPEN-STOP-OPEN-STOP
• CLOSE-STOP-CLOSE-STOP
• OPEN-HOLD TO RUN *
• CLOSE-HOLD TO RUN
4. To confirm the setting, press the “P” button to save and return to the main menu
screen.
NOTE: The above process is the same for Input Command for Input 2 & Input 3.
* If a latching toggle swtich is used, this will override timer-to-close.
SP
+-
MAIN MENU
INPUT 1
figure 1
