Merlin Slide 600 - Introduction; 3 Tools Needed; 4 Overview of the Gate Opener; 5 Installing the Warning Labels

6
INTRODUCTION
TOOLS NEEDED
3
OVERVIEW OF THE GATE OPENER
4
Gate
Opener
Limit Switch
Brackets
Limit Switch
Brackets
Gate
Remote
Control
T
ransformer Box
mounted near 240V
power supply
(MGTR1-96VA)
NOTE: Only required
for MGSK600-LV
low voltage 24V sales kit
MGSK600 – MAINS VOLTAGE SLIDE GATE OPENER INSTALL OR
MGSK600-LV – LOW VOLTAGE SLIDE GATE OPENER INSTALL
Gate
Opener
Limit Switch
Brackets
Limit Switch
Brackets
Gate
Persons are to keep clear! The gate is able to
be moved without prior warning.
Do not let children operate the gate or play in
the gate area.
Moving Gate Can Cause
Serious Injury Or Death
132A3224-01
WARNING
Warning Label
placed within
the inside of
the post
Remote
Control
T
ransformer Box
mounted near 240V
power supply
(MGTR1-96VA)
NOTE: Only required
for MGSK600-LV
low voltage 24V sales kit
2 x Warning Labels are provided with each sales kit (MGS600 & MGS600-LV).
Both warning labels must be placed; one on the inside of the post and the other
on the outside of the post.
INSTALLING THE WARNING LABELS
5
Persons are to keep clear! The gate is able to
be moved without prior warning.
Do not let children operate the gate or play in
the gate area.
Moving Gate Can Cause
Serious Injury Or Death
WARNING
132A3224-01
MGSK600 – MAINS VOLTAGE SLIDE GATE OPENER INSTALL OR
MGSK600-LV – LOW VOLTAGE SLIDE GATE OPENER INSTALL
