Merlin Slide 600 - Programming Flow Chart; 47 Basic Settings - Part 1

38
PROGRAMMING FLOW CHART
BASIC SETTINGS - PART 1
47
Main Menu
1st -Select
Motor/Application
Slider MGS600
Slider GGS1000
Articulated Arm
Single
Articulated Arm
Dual
Linear Arm
Single
Linear Arm
Dual
2nd -Direction
Motor 1
Press & Hold '+'
Gate Opening
Yes 'P', no 'S'
Change Direction
'P' to Execute
3rd -Direction
Motor 2
Change Direction
'P' to Execute
4th -Limit & Force
Learn
Press 'S' to Stop
5th -Exit ( & Save)
Press & Hold '+'
Gate Opening
Yes 'P', no 'S'
