PROGRAMMING FLOW CHART
BASIC SETTINGS - PART 3
47
Main Menu
Delay Motor 1
- Close
No Delay
1 Second
Delay
...
19 Second
Delay
20 Second
Delay
Timer -To-Close
2 Second
Delay
TTC Disabled
Setting TTC
10 Seconds
Setting TTC
20 Seconds
Setting TTC
30 Seconds
Setting TTC
45 Seconds
Setting TTC
1 Minute
Setting TTC
2 Minutes
Setting TTC
3 Minutes
Setting TTC
5 Minutes
Disable
Ram Blow
1 Second
Ram Blow
2 Seconds
Reversal TIme
Open/Close
2 Second
Reversal
Reversal to
Limit
Close:Rev to
Open Limit
Open: Rev 2 Sec
E - Lock
Disabled
E-Lock,
1 Second
E-Lock,
2 Seconds
Mag-Lock
Ram Blow
Flashing Light
Disabled
Continuous
Flashing
