 Refer to the table below. Enter numbers in the "SQA-V Value" column
that corresponds to the SQA-V system parameters printout. Compare
the values. If the value from the SQA-V is within range mark the
"Pass" column. If not, mark the "Fail" column.

# Parameter
S/W Ver. 2.60
S
Q
A-V Value Pass Fail
1. Ref 1 150 – 400 mV
2. LED Cur 1 5 – 25 mA
3. Amplitude 50 – 100 mV
4. Zero Level 500 - 525
5. Ref 2 2500 – 3500 mV
6. LED Cur 2 10 – 32 mA
7. CONC. 1 0 – 1 M/ml
8. CONC. 2 50-150 M/ml
9. CONC. 3 300-600 M/ml
10.
Count (Service
Data, Item #12)
26 - 36
