Revision 21_Sep_2015 4
User Guide Version 2.60 I-button WHO 5th
Specifications
Version 2.60
SECTION 1: System Specifications and Requirements
Dimensions: 32 X 30 X 24 cm
Weight: 7 Kg
AC power supply: 100-240 VAC, 50-60 Hz, 20 VA
Archive Capacity
500 test records / 750 QC records
Display(s)
Operational backlight LCD (16 lines x 40 characters)
Video backlight LCD (8 x 10 cm)
Factory Default Settings
SYSTEM:
Date format: DD/MM/YY
Time/Date: Manufacturer's local time/date
Morphology: WHO 5
th
Chamber standard: 2
Printing Options: Automatic
CONTROLS:
Control Media: Latex Beads, Stabilized Sperm CAP or MES (Lot #, Target Values, +/- Ranges set up by user)
Front Panel
Displays: LCD video display and controls, LCD operational display.
Testing: Measurement compartment, Visualization compartment.
Other: Multi-button keypad, I-Button port, Focus knob, Built-in printer.
Keypad
Operational keys: ON/OFF, TEST, PRINT, SERVICE, ARCHIVE (now disabled),
DELETE, ENTER, four cursor buttons, ESC, ten numeric buttons (0-9).
Video control keys: ZOOM IN/OUT, ILLUMINATION HIGH/LOW, and
MONITOR ON/OFF.
Measurement Compartment
Sources of radiant energy - two LEDs for motility and spectrophotometry
channels.
Detector system - two photo detectors - Motility and Optical Density.
Operating System
Analysis Time: Normal Test–75 seconds; Low Quality–2 additional minutes;
Postvasectomy – 5 minutes.
Software: Resides on flash memory and drives all man-machine interface
functions, runs algorithms for test measurements, and operates visual and
automated screens. System can be upgraded from a PC CD-ROM.
Motility channel input signal: Analog, up to 5V.
Spectrophotometer channel input signal: Modulated(kHz)analog,up to 5V.
Printer
Built-in, Dot Matrix with ribbon cassette (Citizen).
Non-thermostatic narrow paper with 20 characters per line (Citizen).
Rear Panel
Power connector w/fuse-holder (fuse 250V,1A), Video connector,RS232 outlet.
