Revision 21_Sep_2015 26
User Guide Version 2.60 I-button WHO 5th
Service
Menus
SECTION 8: Service Menu
System set-up, maintenance and calibration can be performed from the SERVICE MENU.
To activate this screen, press SERVICE in the MAIN MENU.
SERVICE MENU
SERVICE DATA
SERVICE PERSONNEL
PRINT SELF-TEST DATA
ADD I-BUTTON TESTS
Service Data Communication between the SQA-V and a PC via the RS232
interface is established through the SERVICE DATA screen.
System set-up and upgrades are also performed through
this screen.
The SQA-V archive can be transferred to a PC only when this
screen is activated.
Service
Personnel
A code is required to access SERVICE PERSONNEL. This option
allows a qualified service technician to access calibration and
maintenance settings.
Print SQA-V
SELF-TEST DATA
The system SELF-TEST DATA can be printed from this option.
Please note:
Go to the SQA-V to
load I-button tests
directly to the device.
Add I-Button
Tests
From the SQA-V MAIN MENU SELECT: SERVICE > ADD I-
BUTTON TESTS and follow the on screen instructions seen below:
TO LOAD I-BUTTON TESTS:
1. SLIDE I-BUTTON UNDER THE CLIP
2. PRESS DOWN FIRMLY
3. BUTTON MUST CONTACT PORT EDGES
PRESS ENTER
CONTINUE TO HOLD BUTTON
The I-Button loading screen below will appear:
PLEASE WAIT
I-BUTTON LOADING
The screen below will be displayed after successfully loading tests:
# OF TESTS ADDED: 100
# OF TESTS NOW REMAINING: 110
PRESS ESC TO EXIT
