MESI ABPI MD - Page 25

25
DETAILED INSTRUCTIONS
Black cu on
right leg
Green cu on
left leg
Yellow cu on
left arm
Option 2.2: ABI
measurement
with 3 cus
(left arm)
Place the appropriate cu on the left/right arm and position the cu
1-2 cm above the elbow joint. Make sure that the arrow-shaped
ARTERY marking is in line with the brachial artery.
ARM CUFF
