MESI ABPI MD - Performing the ABI Measurement

27
DETAILED INSTRUCTIONS
PERFORMING
AN ABI
MEASUREMENT
5.3.2
Turn on the device by holding the ON/
OFF button for 2 seconds.
Step 1
Amputation option: If a patient has an
amputated limb or is not compliant for
ABI measurement due to severe and/or
painful wounds, the ABI can be measured
only on patient’s existing limbs. Before the
measurement, the user can disable the
selected cu by clicking the button and
selecting the limb that is not compliant for the
measurement.
Step 2
Apply the cus to the appropriate locations
(arms/legs) according to Chapter 5.3.1 Cu
placement and follow the onscreen instructions.
The patient should be in a supine position, lie
still and remain quiet. Press the START button to
begin the measurement.
Step 3
