47
Phenomenon
Electrostatic
discharge (ESD)
IEC 61000-4-2 e)
Professional healthcare
facility environment
± 8 kV Contact
± 2, 4, 8, 15 kV Air
Signal input/output parts PORT
Electrical fast
transient/bursts
IEC 610004-4 b, f)
± 1 kV
100 kHz Repetition frequency
Immunity test levels
Home healthcare
environment
Surges
Line-to ground a)
IEC 61000-4-5
± 2 kV (not applicable)
Conducted distur-
bances induced
by RF fields
IEC 61000-4-6
b) d) g)
3 V (h)
150 kHz - 80 MHz
6 V(h) in ISM bands between 150 kHz - 80 MHz c)
80% AM 1 kHz c)
3 V (h)
150 kHz - 80 MHz
6 V(h) in ISM and amateur radio
bands between 150 kHz - 80 MHz c)
80% AM 1 kHz c)
STANDARD COMPLIANCE
Comment:
a) This test applies only to output lines intended to connect directly to outdoor cables.
b) SIP/SOPS whose maximum cable length is less than 3 m in length are excluded.
c) Testing may be performed at other modulation frequencies identified by the RISK MANAGEMENT
PROCESS.
d) Calibration for current injection clamps shall be performed in a 150 Ω system.
e) Connectors shall be tested per 8.3.2 and Table 4 of IEC 61000-4-2:2008. For insulated connector shells,
perform air discharge testing to the connector shell and the pins using the rounded tip finger of the ESD
generator, with the exception that the only connector pins that are tested are those that can be contacted
or touched, under conditions of INTENDED USE, by the standard test finger shown in Figure 6 of the
general standard, applied in a bent or straight position.
f) Capacitive coupling shall be used.
g) If the frequency stepping skips over an ISM or amateur radio band, as applicable, an additional test
frequency shall be used in the ISM or amateur radio band. This applies to each ISM and amateur radio
band within the specified frequency range.
h) r.m.s., before modulation is applied.
i) The ISM (industrial, scientific and medical) bands between 150 kHz and 80 MHz are 6,765 MHz to 6,795
MHz; 13,553 MHz to 13,567 MHz; 26,957 MHz to 27,283 MHz; and 40,66 MHz to 40,70 MHz. The amateur
radio bands between 0,15 MHz and 80 MHz are 1,8 MHz to 2,0 MHz, 3,5 MHz to 4,0 MHz, 5,3 MHz to 5,4
MHz, 7 MHz to 7,3 MHz, 10,1 MHz to 10,15 MHz, 14 MHz to 14,2 MHz, 18,07 MHz to 18,17 MHz, 21,0 MHz to 21,4
MHz, 24,89 MHz to 24,99 MHz, 28,0 MHz to 29,7 MHz and 50,0 MHz to 54,0 MHz.
