3.3.1.4 Operating state
The polarity of each input can be selected as follows.
• Value
= 0 Normally Open, the signal is ON when the sensor is enabled. The LED light is on when the sensor is enabled.
• Value
= 1 ormally Closed, the signal is ON when the sensor is disabled. The LED light is on when the sensor is disabled.
Example of configuration of the first connected S module, with 8 NC inputs: Activation Status Module 1 = 255
Example of configuration of the third connected S module, with 4 inputs X1…X4 NC and 4 inputs X5…X8 NO: Activation Status Module
3 = 240
3.3.1.5 Signal persistence
This function is designed to keep the input signal active for a minimum time corresponding to the set value, thus allowing the PLC to detect
signals with low persistence times.
• Value
= 0 - 0 ms ms: filter off.
• Value
= 1 - 15 ms: signals with activation/deactivation times less than 15 ms are kept active for 15 ms.
• Value
= 2 - 50 ms: signals with activation/deactivation times less than 50 ms are kept active for 50 ms.
• Value
= 3 - 100 ms: signals with activation/deactivation times less than 100 ms are kept active for 100 ms.
Example of configuration of the first connected S module, with 8 inputs with a persistence time of 15 ms:
Signal persistence 1 - 4 = 85
Signal persistence 5 - 8 = 85
3.3.1.6 Input filter
This time filter can be set individually for each input and it is used to filter signals lasting less than the set time and NOT to detect them.
This function can be used to avoid detecting false signals.
• Value
= 0 - 0 ms: filter off.
• Value
= 1 - 3 ms: signal state changes less than 3 ms are not detected.
• Value
= 2 - 10 ms: signal state changes less than 10 ms are not detected.
• Value
= 3 - 20 ms: signal state changes less than 20 ms are not detected.
Example of configuration of the first connected S module, with 8 inputs and 20 ms input filter:
Input filter 1 - 4 = 255
Input filter 5 - 8 = 255
Object: No.1 - No.6 08 Digital Inputs 02282S01
Module Parameter Function Default value Default
1°
Par1 Polarity 1-8 0 PNP
Par2 Operating state 1-8 0 NO
Par3 Signal persistence 1-4 0 Disabled
Par4 Signal persistence5-8 0 Disabled
Par5 Input filter 1-4 85 3 ms
Par6 Input filter 5-8 85 3 ms
2°
Par7 Polarity 1-8 0 PNP
Par8 Operating state 1-8 0 NO
Par9 Signal persistence 1-4 0 Disabled
Par10 Signal persistence 5-8 0 Disabled
Par11 Input filter 1-4 85 3 ms
Par12 Input filter 5-8 85 3 ms
3°
Par13 Polarity 1-8 0 PNP
Par14 Operating state 1-8 0 NO
Par15 Signal persistence 1-4 0 Disabled
Par16 Signal persistence 5-8 0 Disabled
Par17 Input filter 1-4 85 3 ms
Par18 Input filter 5-8 85 3 ms
4°
Par19 Polarity 1-8 0 PNP
Par20 Operating state 1-8 0 NO
Par21 Signal persistence 1-4 0 Disabled
Par22 Signal persistence 5-8 0 Disabled
Par23 Input filter 1-4 85 3 ms
Par24 Input filter 5-8 85 3 ms
5°
Par25 Polarity 1-8 0 PNP
Par26 Operating state1-8 0 NO
Par27 Signal persistence 1-4 0 Disabled
Par28 Signal persistence 5-8 0 Disabled
Par29 Input filter 1-4 85 3 ms
Par30 Input filter 5-8 85 3 ms
6°
Par31 Polarity 1-8 0 PNP
Par32 Operating state 1-8 0 NO
Par33 Signal persistence 1-4 0 Disabled
Par34 Signal persistence 5-8 0 Disabled
Par35 Input filter 1-4 85 3 ms
Par36 Input filter 5-8 85 3 ms
Object: No.1 - No.3 16 Digital Inputs 02282S06
Module Parameter Function Default value Default
1°
Par1 Polarity 1-8 0 PNP
Par2 Polarity 9-16 0 PNP
Par3 Operating state 1-8 0 NO
Par4 Operating state 9-16 0 NO
Par5 Signal persistence 1-4 0 Disabled
Par6 Signal persistence 5-8 0 Disabled
Par7 Signal persistence 9-12 0 Disabled
Par8 Signal persistence 13-16 0 Disabled
Par9 Input filter 1-4 85 3 ms
Par10 Input filter 5-8 85 3 ms
Par11 Input filter 9-12 85 3 ms
Par12 Input filter 13-16 85 3 ms
2°
Par13 Polarity 1-8 0 PNP
Par14 Polarity 9-16 0 PNP
Par15 Operating state 1-8 0 NO
Par16 Operating state 9-16 0 NO
Par17 Signal persistence 1-4 0 Disabled
Par18 Signal persistence 5-8 0 Disabled
Par19 Signal persistence 9-12 0 Disabled
Par20 Signal persistence 13-16 0 Disabled
Par21 Input filter 1-4 85 3 ms
Par22 Input filter 5-8 85 3 ms
Par23 Input filtert 9-12 85 3 ms
Par24 Input filter 13-16 85 3 ms
3°
Par25 Polarity 1-8 0 PNP
Par26 Polarity 9-16 0 PNP
Par27 Operating state 1-8 0 NO
Par28 Operating state 9-16 0 NO
Par29 Signal persistence 1-4 0 Disabled
Par30 Signal persistence 5-8 0 Disabled
Par31 Signal persistence 9-12 0 Disabled
Par32 Signal persistence 13-16 0 Disabled
Par33 Input filter 1-4 85 3 ms
Par34 Input filter 5-8 85 3 ms
Par35 Input filter 9-12 85 3 ms
Par36 Input filter 13-16 85 3 ms
