METER AQUALAB User Manual

6
ABOUT THE VSA
Table1 AQUALAB VSA button icons
Icon Name Action
Enter
Accepts the current action
CANCEL Ends the current action
MENU
Switches between the Isotherm, Measurement, Configuration, and
Data tabs
SAVE Saves a setting or a reading
OK Accepts the input from the user
GRAPH Shows graph view
WIZARD Brings up Test Setup Wizard
AUDIO OFF Silences beeping
AUDIO ON Enables beeping
2.4.1 ISOTHERM TAB
The Isotherm tab is the main screen and displays each time the VSA turns on. If the Isotherm
tab screen does not appear, refer to Section9.1 for troubleshooting. Operators can initiate
a new test from this screen by pressing the wizard icon (third button from right). If a test is
already running, this screen displays the latest test values including water activity, weight or
% moisture content and temperature. Pressing the second button activates the chart view.
Figure 1 Isotherm tab
