28
INSTALLATION
Table 1 Installation (continued)
Installation
(continued)
Plug In Instrument
Plug the power cord into the back of the unit and an outlet.
Only use the supplied power cord or one rated for VSA and certified for the
country of use. The cord must be a minimum of 18 AWG and have a rating for
10A or greater.
An incorrect main power voltage can damage the instrument.
Turn the Unit ON
Use the power switch on the back of the instrument to turn it on.
Allow the VSA a 2-h warm-up period to bring the scale into constant operating
temperature and ensure accurate readings.
Leave the VSA powered on when not in use to maintain optimal instrument
speed and performance. When not in use, the VSA will automatically enter
standby mode.
Install Desiccant Tubes
Firmly seal the desiccant tube lid onto the desiccant tube.
Remove the black vinyl covers from the air fittings.
Lift the desiccant tube into the area above the desiccant receiver and then
insert the fittings into the mating holes. Ensure the black fitting is placed into
the corresponding black hole. The desiccant tube is sealed for flow purposes
even if it may feel loose.
Desiccant installation
Install Air Cylinder and Weighing Pan
Verify the air cylinder and weighing pan are clean. Avoid dropping the parts to
avoid damage that may affect performance.
Open the VSA lid.
To Next Page
