INSTALLATION
Table 1 Installation (continued)
Installation
(continued)
Fill the Water Tank
Remove the black plug on the clear plastic tank fill extension located on the
back right of the VSA.
Tank fill extension
Fill the tank with steam distilled water until full to top.
Reinstall the black plug once finished. The black plug should be hand
tightened only.
NOTE: Use the water tank drain plug to remove the water from the water tank. Place a
receptacle below the plug to catch the water flow.
Connecting
Connect to Computer
Insert the USB drive from the Moisture Analysis Toolkit booklet into a Windows
computer.
Open the Moisture Analysis Toolkit application and click through the
installation wizard to download the software.
Remove the USB drive.
Plug in the USB cord into a Windows PC USB port and into the VSA COM port.
Open the Moisture Analysis Toolkit Software.
Select the METER USB COM port in the toolbar.
Click Connect.
