8
99-6507
DASH DISASSEMBLY
JEEP GRAND CHEROKEE 2005-2007
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unsnap and remove panel from around
radio including the vent on each side.
(Figure A)
1
2
Remove (4) 7MM screws securing radio.
Unplug and remove radio. (
Figure B)
3
A
B
Continue to kit assembly.
