DASH DISASSEMBLY
7
DODGE CALIBER 2007
JEEP COMPASS 2007
JEEP PATRIOT 2007
1
2
34
5
6
L
D
L
D
N
R
P
A
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unsnap and move shifter trim to the side.
(
Figure A)
1
2
4
Remove (4) 7MM screws securing radio.
Unplug and remove radio.
6
Continue to kit assembly.
Unsnap center dash trim panel (do not
remove until climate controls are
removed).
(Figure A)
5
Remove (4) Phillips screws holding
climate control panel to backside of
the center dash panel.
7
3
(Compass and Patriot only) Unspap and
remove top center dash panel above AC
vents.
