Metra Electronics 99-6507 - ISO Radio Provision with Pocket Assembly

13
99-6507
KIT ASSEMBLY
ISO RADIO PROVISION WITH POCKET
1
Mount the ISO Brackets to the
radio using the screws supplied
with the radio.
Figure A
2
Slide the radio into the opening
until it snaps into place. Figure B
3
Using the alignment pins on the
trim plates & the corresponding
holes in the housing, attach the
upper trim plate and the lower trim
plate supplied with the kit.
Figure B
A
B
NOTE: You will need to remove the
aftermarket radio’s trim ring if
equipped.
4
Continue to Final Assembly.
