99-6507
DASH DISASSEMBLY
10
CHRYSLER PT CRUISER 2006-2007
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Remove (2) screws from inside air vents
on center dash panel. (
Figure A)
1
2
3
Remove (4) 7MM screws securing radio.
Unplug and remove radio.
5
A
Continue to kit assembly.
Unsnap center dash panel (do not remove
until climate controls are removed).
(Figure A)
4
Remove (4) Phillips screws holding climate
control panel to backside of the center
dash panel.
6
To Next Page
