99-6507
DASH DISASSEMBLY
6
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unsnap and remove console front top
cover (closest to the dash). (
Figure A)
1
3
Unclip and remove entire panel surrounding
radio and climate controls, including a/c
vents. (Figure E)
7
Remove (4) 7MM screws securing radio
to dash and remove radio.
8
A
B
If vehicle has floor shifter, remove shifter
knob.
2
D
E
Remove two 8 mm screws from under
console cover (previously removed).
Remove front section of console.
(
Figure B)
4
5
Loosen two 8 mm screws at bottom of
dash. Unsnap lower panel.
Remove (2) Phillips screws facing up on
front edge of radio/climate control panel.
(
Figure D)
6
Continue to kit assembly.
9
DODGE RAM 2006-2007
WITH FULL CENTER CONSOLE
To Next Page
