99-6507
DASH DISASSEMBLY
11
MITSUBISHI RAIDER 2006-2007
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unsnap and remove center dash panel.
(
Figure A)
1
2
3
Remove (4) 7MM screws securing radio.
Unplug and remove radio.
4
A
Continue to kit assembly.
