99-6507
DASH DISASSEMBLY
4
DODGE RAM 2006-2007
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Open cup holder and remove (2) Phillips
screws facing up on front edge of
radio/climate control panel. (Figure A)
1
2
Unclip and remove entire panel sur-
rounding radio and climate controls,
including a/c vents. (
Figure B)
3
Remove (4) 7MM screws securing radio.
Unplug and remove radio.
4
A
B
WITHOUT CENTER CONSOLE
Continue to kit assembly.
5
To Next Page
