9
99-6507
DASH DISASSEMBLY
JEEP COMMANDER 2006-2007
4
screws
4
screws
4
screws
4
screws
A
B
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Remove the (16) screws securing the
radio trim panel. (Figure A)
1
2
Unclip and remove the entire radio trim
panel. (Figure B)
3
Remove (4) 7MM screws securing radio. Unplug and remove radio.
4
Continue to kit assembly.
5
