99-6507
DASH DISASSEMBLY
3
CHRYSLER 300 2005-2007
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unclip and remove entire panel surround-
ing radio and climate controls, including
a/c vents and clock. (
Figure A)
1
2
Remove (4) 7MM screws securing radio.
Unplug and remove radio. (
Figure B)
3
B
A
Continue to kit assembly.
4
To Next Page
