2
99-6507
DASH DISASSEMBLY
DODGE MAGNUM 2005-2007
DODGE CHARGER 2005-2007
Disconnect the negative battery terminal
to prevent an accidental short circuit.
Unclip and remove entire panel surrounding
radio and climate controls, including a/c
vents. (
Figure A)
1
2
Remove (4) 7MM screws securing radio.
Unplug and remove radio. (Figure B)
3
A
B
Continue to kit assembly.
4
To Next Page
