MD 9273 Leakage Clamp Description of Test Functions
13
3 Description of Test Functions
Main Test Functions of the Leakage Clamps, selectable with rotary switch position, are:
• Current test measurement – position mA, A
• Voltage test measurement - position V
• Power test measurement - position W
• In the position of the rotary switch, clamps are controlled by the connected device.
Beside Main test function, sub function test can be selected with keyboard buttons. See Chapter Flowcharts
of sub-function selection for details.
3.1 Main Test function connection schemes
Appropriate jaws and test leads connection schemes for each selected main function are presented on Figure
3.1: Test function connection schemes below.
mA, A – Current test
V – Voltage test
W – Power test
Figure 3.1: Test function connection schemes
